HALO-6 Pals (CHIRP) Radar

Featured Information

Compass Safe :

STD. 1.0 m (3.3 ft) Steer 0.5 m 1.6 ft)

Dimensions W x H x D :

324 x 427 x 339 mm (12.76 x 16.81 x 13.35 in)

Weight :

Pedestal: 18.75 Kg (41.3lb) Antenna: 6.5 Kg (14.3 lb)

HALO-6 Pals (CHIRP) Radar

PHYSICAL

Compass Safe : STD. 1.0 m (3.3 ft) Steer 0.5 m 1.6 ft)
Dimensions W x H x D : 324 x 427 x 339 mm (12.76 x 16.81 x 13.35 in)
Weight : Pedestal: 18.75 Kg (41.3lb) Antenna: 6.5 Kg (14.3 lb)

ENVIRONMENTAL

Humidity : IEC60945 Exposed product
Operating Temperature Range : -25°C to +55°C (-13°F - 131°F)
Shock Vibration : IEC60945 Exposed product and 20G, 100,000 cycle
Waterproofrating : IPX6

APPROVALS

Approvals Compliance : FCC/IC/R&TTE Type Certifi cationFCC ID: RAYHALOIC ID: 4697A-HALOR&TTE: Emissions compliant to SM1541-4 (including -40dB/dec future design objectives)

OTHER

Interface : Simrad or B&G Ethernet MFD
Languages : See Radar Controller
Warranty Period : 2 Years

ELECTRICAL

Power Consumption Max : 180 W (peak) at maximum wind velocity
Power Consumption Typical : 40 W (average) at zero wind velocity6.5 W (average) for Scanner + RI-12 in Standby mode
Recommended Fuse Rating : 25A for 12V systems or 15A for 24V
Supply Voltage : 12V Systems 10.8 - 15V DC 24V Systems 20 - 31.2V DC

CONNECTIVITY

Ethernet Ports : RI-12, 1 x 100 Mbit RJ45 Adapter to 5 pin yellow supplied)
N2K PG Ns : 127250 - Vessel Heading, 127251 - Rate of Turn, 129025 - Position, Rapid Update, 129026 - COG & SOG, Rapid Update, 129029 - GNSS Position Data, 130818 - Proprietary
NMEA 0183 Sentences Supported : Sentenses used by the radar application. HDG, HDT, HDM,GGA, GLL, RMC, VTG.Baud rate: Auto sense 4800, 9600, 19200 or 38400
NMEA 2000 Connectivity : RI-12, 1 x NMEA2000, Micro-C, 1 LEN

RADAR

Beam Width : 1.2°+/-10% (-3 dB width) - 0.8 deg with Beamsharpening mode ON:Vertical: 25° +/-20 % (-3 dB width)
Max Range, Scale : 72 nm
Max Wind Speed : 70 kn
Min Range, Scale : 75 m (300 ft)
Radar Modes : Head Up, North Up
Radar Technology : Pulse Compression
Sart Racon : Yes – trigger distance: about 1nm max – weather, seastate, and SART position dependent

HALO-6 Pals (CHIRP) Radar

Combining the best features of traditional pulse and FMCW (Frequency Modulated Continuous Wave) broadband radar systems, Halo ™ Radar offers unprecedented technology with a long and short detection range, high target identification and minimal complexity. Thanks to Impact Compression technology and Solid-State technology, it provides minimum warm-up time and transatlantic reliability. Low-power pulse broadcasts safely operate Halo Radar in iron fields and marinas.
