FLIR DM93-2

Industrial Digital Multimeter with METERLiNK®

FLIR DM93-2

Industrial Digital Multimeter with METERLiNK®

Featured Information

Display Counts :

40,000

FLIR DM93-2

Industrial Digital Multimeter with METERLiNK®

Specifications

Display Counts : 40,000

Measuring Rate : 10 samples per second
Resistance : 40.00 MΩ ± 0.2%
Temperature Range : -200°C to 1200°C (-328°F to 2192°F) ±1.0%
Temperature Type K thermocouple : Yes
VFD AC Voltage : 1000.0 V ± 0.5%

Power

Auto Power Off : Default: 10 minutes
Battery life : ~100 hours with alkaline batteries (backlight, worklight, and Bluetooth off)
Battery type : 6 × 1.5 V AAA alkaline batteries

Environmental & Certifications

Certifications : UL, CE, FCC, UKCA
Drop test : 3 m (9.8 ft)
IP Rating : IP54 dust-protected and splash-resistant
Warranty : https://www.flir.com/testwarranty

Measurement & Analysis

AC Current : 10.000 A ± 1.0%
AC Voltage : 1000.0 V ± 0.5%
Capacitance : 40.00 mF ± 0.9%
Category Rating : CAT IV-600 V, CAT III-1000 V
Continuity Threshold : 30 Ω ± 0.2%
DC Current : 10.000 A ± 0.2%
DC Voltage : 1000.0 V ± 0.05%
Diode Test : 2 V ± 1.5%
Display Counts : 40,000
Frequency : 100.00 kHz ± 5 digits

Communication & Data Storage

Bluetooth range max : 10 m (32 ft)
Data Recording : 10,000 records with METERLiNK
Memory : 99 internal storage locations

General

Packaging Size : 28.5 cm × 15 cm × 10.4 cm (11.22 in × 5.91 in × 4.09 in)
Size (L x W x H) : 207.1 mm × 98.1 mm × 60.7 mm (8.15 in × 3.86 in × 2.39 in)
Weight : 601 g (1.33 lb) including batteries
Worklights : Yes

FLIR DM93-2

Industrial Digital Multimeter with METERLiNK®

The FLIR DM93-2 is a world-class digital multimeter with advanced variable-frequency drive (VFD) filtering to help you accurately analyze non-traditional sine waves and noisy signals found in VFD-controlled equipment. No matter what electrical challenge you’re up against, the DM93-2’s powerful lighting and durable design is up to the job. Use the METERLiNK® app to quickly and efficiently capture readings, images, and videos for analysis, trending, and sharing.
