Featured Information
FCB-624-AI
Analytics
- Analytics Features Target classification (human, vehicle), Geo-location, PTZ tracking handoff, Tamper detection
- False Alarm Rejection Deep Neural Network (DNN) & CNN analytics to eliminate nuisance alarms from foliage, rain, and headlights
Cybersecurity
- Security Protocols Password protection, Password policy enforcement, IP filtering, IEEE 802.1X, Digest authentication, HTTPS, User access log
Environmental
- Operating Temperature -40°C to +60°C (-40°F to 140°F)
- Storage Temperature -50°C to +85°C (-58°F to 185°F)
- Humidity 5% – 95% (non-condensing)
- IP Rating IP66 & IP67 / NEMA 4X
- Vandal Resistance IK10
- De-icing / Defogging Automatic window heater
Thermal Optical
- Sensor Type Uncooled Sun-safe VOx Microbolometer
- Thermal Resolution 640 × 512 (VGA)
- Pixel Pitch 12 µm
- Thermal Sensitivity (NETD) <20 mK @ f/1.0
- Focal Length 18 mm
- Field of View (HFOV × VFOV) 24.3° × 19.5°
- f-number f/1.0
- Spectral Range 8 µm to 14 µm
Compliance & Certifications
- NDAA Compliant Yes (Meets NDAA standards through rigorous security testing)
- Certifications CE, FCC Class A, UL, RoHS, WEEE
- ONVIF Conformance Profile S, Profile G, Profile T
Physical & Integration
- Dimensions 267 × 124 × 127 mm (10.5 × 4.9 × 5.0 in)
- Weight 1.8 kg (3.97 lb)
- Power Options PoE+ (IEEE 802.3at), 12 VDC, 24 VAC
- Power Consumption Max 24 W (with heaters)
- Local Storage MicroSD / MicroSDHC / MicroSDXC (up to 512 GB)
- Alarm I/O 1 Alarm Input, 1 Relay Output
The FCB-Series AI thermal security camera turns noisy, cluttered sites into clear, dependable views your team can act on. With industry-leading thermal sensitivity (<20 mK), it visualizes objects through fog, drizzle, and night-time glare, so a person slipping between stacked containers or walking along a dark campus fence line doesn’t vanish in the shadows. Onboard AI analytics distinguish people and vehicles from swaying trees or rain on the lens, cutting the nuisance alarms that currently flood your VMS. Nexus-enabled geolocation and PTZ handoff let operators click on a target and follow it around corners, along the fence, or between buildings, while flexible lens options and an IP67 housing make it easy to cover awkward yard layouts, loading bays, and remote installations.
