MO24-T Monitor
MO24-T Monitor
POWER
- Power Consumption : 60W
- Power Supply : 12/24V
TECHNICAL
- Width : 24.6 inches / 625 mm
- Depth : 2.9 inches / 74 mm
- Height : 15.2 inches / 386 mm
- Display Viewing Angle H/V deg. : 80/80/80/80
- Contrast Ratio : 5000:1
- USB : USB Type-B Plug on rear for alternate touch screen connection
- Serial : 4 way serial plug on rear for touch screen connection via RS422 to NSO evo2
- Picture in Picture : Yes, Variable size and position
- Thermal Protection : Automatic - Backlight reduced to 10%
- Menu Languages : English, French, German, Spanish, Italian, Portuguese
DISPLAY
- Display Resolution : 1024x768 (XGA 4:3), 1280x720 (HD 16:9), 1366x768 (WXGA), 1920x1080 (Full HD 16:9), 1920x1200 (WUXGA 16:10), 1280x800 (16:10), 1280x1024 (SXGA 5:4)
SPESIFICATIONS
- Enclosure : ABS Plastic Rear Case, Glass Front
- Operating Temperature : -15°C to +55°C
- Non-Operating Temperature : -20°C to +60°C
- Water Ingress : IPx6 (When dash mounted), IPx2 from back
- Weight : 7.04Kg
- Dimensions (WxHxD) mm : 625 x 386 x 74
- Display Brightness : 1000nit
- Display Resolutions : 1920 x 1080
- Display Viewable Area (W x H) mm : 532 x 299
- Display Color Depth : 16.7 Million Colours
Touch Screen-Projected
- Capacitance Multi Touch : Yes
- Operating Voltage : 14 - 31.2 V DC
- Low Power Standby Mode : Yes
- Protection : Reverse polarity and temporary over-voltage to 36V
- Conformity : CE, C-Tick, HDMI
- Power and Setup Keys : Capacitive Touch - Power Key, Up, Enter, Down, Home
- NMEA 2000 : 1 port on rear (Micro-C male)
- Composite Video Inputs : 2 ports on rear (BNC female. NTCSor PAL format)
- Digital Video Inputs : 2 ports on rear (1 x DVI-D, 1 x HDMI)
- Supported Video Resolutions : 640x480(VGA 4:3), 800x600 (SVGA 4:3), 1024x768 (XGA 4:3), 1280x720 (HD 16:9), 1280x800 (16:10), 1280x1024 (SXGA 5:4),1366x768 (WXGA), 1920x1080 (Full HD 16:9), 1920x1200(WUXGA 16:10)
The MO24-T monitor delivers smooth and responsive multi-touch control of your Simrad glass bridge. This 24-inch widescreen, high-bright display is suitable for inside or outside installations, and features a thin bezel designed to maximize viewing area for your available dash or console space.
