FLIR A700-EST
Featured Information
FLIR A700-EST
SPECIFICATIONS
- Digital I/O connector type : M12 12-pin A-coded, Male (shared with external power)
- Digital Inputs : 2x opto-isolated, Vin(low)= 0–1.5 V, Vin(high)= 3–25 V
- Digital Output Purpose : As a function of alarm, output to external device (e.g. when screening alarm is triggered); fault (NC)
- Digital Outputs : 3x opto-isolated, 0–48 V DC, max. 350 mA; solid-state opto relay; 1x dedicated as fault output (NC)
- Ethernet Interface : Wired, Wi-Fi
- WiFi : Yes. RP-SMA, female connector
- EMC : ETSI EN 301 489-1 (radio), ETSI EN 301 489-17 (radio), EN 61000-4-8 (magnetic field), FCC 47 CFR Part 15 Class B (emission US), ISO 13766-1 (EMC - Earth-moving and building construction machinery), EN ISO 14982 (EMC - Agricultural and forestry machinery)
- Measurement Frequency : Up to 10 Hz
- Image Frequency : 30 Hz
- Lens : 24°
COMMUNICATION & DATA STORAGE
- Image Storage : Up to 100 FLIR radiometric JPEGs, stored as a function of alarm, scheduling, or user interaction (camera web)
ENVIRONMENTAL & CERTIFICATIONS
- Lens Transmission Correction : Automatic, based on signals from internal sensors
- Alarm Functions : On any selected measurement function, digital in, internal camera temperature
- Alarm Output : Digital out, email (SMTP) (push), EtherNet/IP (pull), file transfer (FTP) (push), Modbus TCP master write (push), Modbus TCP slave (pull), MQTT (push), Query over RESTful API (pull), store image or video
IMAGING & OPTICAL
- Thermal Sensitivity_NETD [typical] : <40 mK @ 30°C (86°F)
- Visible Camera : Included
USER INTERFACE
- Web interface : Yes
The FLIR A700-EST is a non-contact screening tool that can serve as a first line of defense against potential health risks. This FLIR EST™ thermal screening solution detects and visualizes heat to quickly identify individuals with an elevated skin temperature. The 640 × 480 pixel detector offers the highest thermal resolution in this line of fixed mount FLIR EST cameras, for superior measurement accuracy. Compatibility with industry standards such as Modbus TCP, MQTT, RESTful API for data transfer and RTSP for video makes third-party integration easy. With on-camera FLIR Screen-EST™ Mode and compatibility with FLIR Screen-EST™ Desktop software, the A700-EST can be easily deployed as a single, standalone screening station or in a network.
