FLIR CM-3304-11-I
3864x2180, 4K UHD
FLIR CM-3304-11-I
3864x2180, 4K UHD
Featured Information
Automatic Electronic Shutter [AES] :
1/1 to 1/32,000 (auto)
Day/Night Mode :
Yes
Digital Slow Shutter [DSS] :
1/1(1)~1/60(50) NTSC(PAL)
Dimensions :
161x128.6 mm (6.3 x 5 in.)
Enclosure :
Indoor/Outdoor: IK10 rated vandal IP66
Firmware Upgrade :
Flash memory for upgrade of camera firmware over the network
Input Voltage :
PoE IEEE802.3af, class 0 AC24V, max 13.68 watt
Power Connection :
RJ45 & 24VAC
Power Consumption :
12.5W with heater and IR
Privacy Zones :
Yes
FLIR CM-3304-11-I
3864x2180, 4K UHD
GENERAL
- Automatic Electronic Shutter [AES] : 1/1 to 1/32,000 (auto)
- Day/Night Mode : Yes
- Digital Slow Shutter [DSS] : 1/1(1)~1/60(50) NTSC(PAL)
- Dimensions : 161x128.6 mm (6.3 x 5 in.)
- Enclosure : Indoor/Outdoor: IK10 rated vandal IP66
- Firmware Upgrade : Flash memory for upgrade of camera firmware over the network
- Input Voltage : PoE IEEE802.3af, class 0 AC24V, max 13.68 watt
- Power Connection : RJ45 & 24VAC
- Power Consumption : 12.5W with heater and IR
- Privacy Zones : Yes
COMPLIANCE & CERTIFICATIONS
- International : CE marked, EN61000-6-3 & EN50130-4, RoHS, RCM*
- ONVIF : Profiles S, G & T
- USA UL, FCC Part 15 (subpart B, class A)
ENVIRONMENTAL
- Humidity : 90% (non-condensing)
- Operating Temperature : -30°C~60°C (-22°F~140°F) without heater -55°C~60°C (-67°F~140°F) with heater Cold start -40°C~60°C (-40°F~140°F) with heater
- Storage Temperature : -20°C~70°C (-4°F~158°F)
PTZ
- Pan_Tilt_Spin : 356° / ±80° / ±98°
VIDEO & RECORDING
- Maximum Performance : H.264/H.265 30/25 FPS @ 4K (NTSC/PAL) + 30/25 FPS @ D1 or H.264/H.265 15/12 FPS @ 4K + 1080P + D1 (NTSC/PAL) or H.264/H.265 60/50 FPS @ 1080P + 30/25 FPS @ 720P + D1 (NTSC/PAL)
- Rate Control : CBR, CVBR, LBR, MJPEG
- Resolution Range : Scalable from QCIF to 4K
- SD Card Recording1 : microSD/microSDHC/microSDXC 8GB to 512GB (Class 10)
- Video Motion Detection : Yes
- Scanning Mode : Progressive
- Shutter WDR : 130dB
- Tamper Detection : Yes
- Warranty : According to FLIR RMA Policy and Process Notice document
- Power Consumption : 12.5W with heater and IR
CYBER SECURITY
- Security : Password protection, IP address filtering, TLS/HTTPS, IEEE 802.1X network access control, Digest authentication Password policy Protect from multiple failure login
MEASUREMENT & ANALYSIS
- Automatic Gain Control : Auto
SYSTEM INTEGRATION
- Bi-directional Audio : 1 Audio Line Input, G.711 a/µ-law, AAC support + 1 Audio Line Output
- Distance : Up to 40m (131 ft.) Sunshield 28m (91.8 ft.)
- Ethernet : 10/100/1000, IEEE 802.3, auto sensing 1 x RJ45
- Input : 1 dry alarm contact 1 5V 10kΩ pull up
- Network Protocol : IPV4/6, HTTP, HTTPS, ,UPnP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, IGMP, DHCP, ARP, IEEE 802.1X, SNMP,QoS, TLS, SMTP, FTP, DDNS, PPPoE, RTCP
- Output : 1 Relay Contact max. DC 5V 130MA
- Peak Emission Wavelength [nm] : 850
- Remote Configuration : Via web browser or supported video management software
- Supported Web Browser : Internet Explorer, Firefox, Chrome, Edge, Safari
VISIBLE CAMERA
- Backlight Compensation : On / Off
- Bandwidth : Confgurable between 64Kbps and 20Mbps
- Image Sensor : 1/1.8
- Lens Type : Varifocal 4.46-11mm, 40.43°- 110.76° HFOV, 22.65°-57.14° VFOV, F1.47-F2.5, D/N, Zoom, Auto-Focus / Auto-Iris, P-Iris
- Mechanical IR Cut Filter : Yes
- Noise Reduction : 3D/2D/Color
- Sensitivity : 0.04 (color)/0.002 (BW), 0 Lux with IR illuminator ON, measured at 30 IRE
- Sensor Resolution : 3864×2180
- Signal to Noise Ratio : ±50 dB
- White Balance : Auto / ATW / Manual / One Push
FLIR CM-3304-11-I
3864x2180, 4K UHD
The Ariel Quad HD Mini-Dome camera is designed to provide situational awareness in the most challenging environments where evidence-based and forensic video is required. It delivers superior image quality for exceptional performance while using low bandwidth. Ideal for critical infrastructure sites, remote facilities, or large areas requiring close monitoring, the Ariel Quad HD Mini-Dome is a covert surveillance option that is NDAA-compliant and employs top-tier cybersecurity measures. Its ease of installation, compatibility with the FLIR accessory and mounting ecosystem, and the ability to run multiple cameras on a single server all contribute to a lower total cost of ownership.
