FLIR SV89-KIT

Vibration Monitoring Solution Kit

FLIR SV89-KIT

Vibration Monitoring Solution Kit

Featured Information

Capture Rate :

Configurable: 1 min (minimum) - 1 day (maximum)

Frequency Range :

10 Hz to 10 kHz

Sensitivity Range :

±50 g

FLIR SV89-KIT

Vibration Monitoring Solution Kit

Measurement & Analysis

Capture Rate : Configurable: 1 min (minimum) - 1 day (maximum)
Frequency Range : 10 Hz to 10 kHz
Sensitivity Range : ±50 g
Temperature Range : Display measurement trend of contact temperature -20°C to 80°C (-4°F to 176°F)
Vibration Analysis Data : Grms, Vrms, (ISO10816) Peak, Crest Factor, Kurtosis, Skewness, Standard Deviation, FFT

Power

AC Input : TA87 universal power adaptor: 100 V to 240 V AC, 50/60 Hz (optional)
Battery life : LS17500 3.6 V 3600 mAh Li battery (replaceable)
Battery type : -20° to 80°C (-4°F to 149°F)
LED Indicators : Sensor: Low battery LED; Gateway: WAN, LAN, 2.4 GHz, 5 GHz dual band dual concurrent
PoE : 802.3 at standard PoE (PD) @ WAN port
Power Input : 12 VDC

Environmental & Certifications

Altitude : 2000 m (6,562 ft)
Certifications : ETL/FCC/IC/CE/UKCA/RCM
Drop test : 1 m (3 ft)
Humidity (Operating and Storage) : 10% - 95% relative humidity, non-condensing
IP Rating : Sensor: IP66; Gateway: IP40
Operating Temperature Range : -20° to 80°C (-4°F to 149°F)
Relative Humidity : 10% - 95% relative humidity, non-condensing
Storage Temperature Range : -20° to 80°C (-4°F to 149°F)
Warranty : 3 years

Communication & Data Storage

Communication Protocol : Sensor: TCP Socket; Gateway: MQTT, Modbus, OPC UA
Memory : Sensor: 1 MB Flash; Gateway: DDR3L 512 MB
Output Data : Sensor: 10 KHz, Z: 12,800 raw data; Gateway: Vibration analysis data: Grms, Vrms, (ISO10816), Peak, Crest Factor, Kurtosis, Skewness, Standard Deviation, FFT
Range (During A Session) : Up to 50 m (160 ft), line of sight
Wi-Fi Type : IEEE 802.11n

General

Operating System : Built-in webserver (Linux)
Size (L x W x H) : Sensor: 29 × 25 × 14 mm (1.14 × .98 × .55 in); Gateway: 57.3 × 39.3 × 46.1 mm (2.25 × 1.55 × 1.81 in)
Weight : Sensor: 187 g (6.6 oz); Gateway: 645 g (22.75 oz)

FLIR SV89-KIT

Vibration Monitoring Solution Kit

The FLIR SV89™ Vibration Monitoring Kit helps you monitor critical equipment by continuously analyzing vibrations from rotating equipment, detecting faults, and alerting you to potential defects and future problems. With its Multi-communication protocols, rugged, IP66 rating and wireless capability, the SV88 Vibration Monitoring Solution Kit allows you to make critical data-driven decisions that alert you to potential issues and extend the life of your valuable equipment.
