FLIR MR55
Pin Moisture Meter with Bluetooth®
.png)
FLIR MR55
Pin Moisture Meter with Bluetooth®
Featured Information
Pin Moisture :
Wood Range: 7% to 29% (±2% MC accuracy); 30% to 99% (Reference Only) / Building Material Range: 1% to 99% Group 10, 1 to 35% Group 11 (Reference Only)
Pin Moisture Groups :
Wood Type: Groups 1–9; Building Materials: Groups 10 and 11
Display :
Backlit, multifunction LCD
FLIR MR55
Pin Moisture Meter with Bluetooth®
Specifications
- Pin Moisture : Wood Range: 7% to 29% (±2% MC accuracy); 30% to 99% (Reference Only) / Building Material Range: 1% to 99% Group 10, 1 to 35% Group 11 (Reference Only)
- Pin Moisture Groups : Wood Type: Groups 1–9; Building Materials: Groups 10 and 11
- Display : Backlit, multifunction LCD
Communication & Data Storage
- Connectivity : Bluetooth BLE; Communications Protocol: METERLiNK®
Power
- Auto Power Off (APO) : After 20 minutes
- Battery life : Typical 70 hours without worklight
- Battery status indicator : 4-bar battery icon (100% to empty)
- Battery type : (2) x 1.5 V AA
Environmental & Certifications
- Certifications : CE, RCM, FCC/IC
- Drop test : 2 m (6.6 ft)
- IP Rating : IP40
- Warranty : Limited 3 years
Measurement & Analysis
- Measurement Principle : Electrical resistance using pins
- Pin Moisture : Wood Range: 7% to 29% (±2% MC accuracy); 30% to 99% (Reference Only) / Building Material Range: 1% to 99% Group 10, 1 to 35% Group 11 (Reference Only)
- Pin Moisture Groups : Wood Type: Groups 1–9; Building Materials: Groups 10 and 11
User Interface
- Display : Backlit, multifunction LCD
General
- Dimensions : 188 × 58 × 33 mm (7.4 × 2.3 × 1.3 in)
- Housing material : Impact-resistant plastic
- Weight : 160 g (5.6 oz) battery excluded
The FLIR MR55 is a pin-based meter with wireless connectivity, which offers the convenience to view readings from a mobile device via the METERLiNK® app. Thanks to a built-in library of 11 material groups, users can tune the meter to the appropriate test material to improve measurement accuracy. This library is easy to access on the FLIR.com website by scanning a QR code on the back of the meter with a mobile device.
